LCM160 Uncooled Infrared Thermal Module
- Model:
- LCM160
Features
Resolution
160×120
Pixel Pitch
12μm
Effective Frame Rate
≤25Hz
Typical Power Consumption
Normal mode: 45 mW (typical value)
Shutter pressed: 750mW (typical value)
Shutter pressed: 750mW (typical value)
Package Dimension (W×L×H)
17.9mm×16.8mm×9.9mm (as per drawing)
Highlights
Description
LCM160 is a long-wave infrared (8~14μ m, LWIR) infrared thermal imaging module, which can convert the thermal radiation of the object itself into a digital signal output.
The product is composed of a detector, shutter, a lens, and structural components,the host completes the corresponding ISP algorithm processing. The product is small, light in weight, and low in power consumption, and is suitable for security monitoring, thermal measurement devices, smart home appliances and other fields.
Specifications
Technical Specifications
LCM 160
Overview
Detector type
Vanadium oxide uncooled infrared focal plane detector
IR wavelength
8‑14μm
Pixel pitch
12μm
NETD
<50mK @25℃, F#1.0, 25Hz
Frame Rate
25Hz
Optional Lens
2.6mm
Focusing mode
Athermalized prime lens
Image Adjustment
Brightness/Contrast Adjustment
0‑100 levels selectable
Polarity
White hot / Black hot
Pseudocolor
Supported
Image Processing
Supports on‑chip 4‑bit non‑uniformity correction and shutter correction
Temperature Measurement
Measurement Range
-20℃~150℃ (high image quality), 0℃~550℃ (wide range)
Measurement Accuracy
±2℃ or ±2% of the reading (whichever is greater)
Electrical Parameters
Power Supply Voltage (Typical)
5V (analog), 1.8V (digital)
Power Consumption @ 25℃
<0.045W
Digital Video
8‑bit standard parallel port
Serial Communication Interface
I2C
Physical Characteristics (lens & flange not included)
Dimensions
17.9mm×16.8mm×9.9mm
Weight
2.4g
Environment
Operating Case Temperature
-20℃ ~ +60℃
Storage Case Temperature
-45℃ ~ +85℃
Humidity
5%‑95%, non‑condensing
Random Vibration
6.06g, all axes
Shock
Half‑sine waveform, 25g, 11ms, 3 axes
