Highlights
Description
The NS-615AS-10GE is an area scan infrared camera featuring an InGaAs detector, built-in image correction and processing algorithms, and a 10GigE vision interface, supporting full-window output at up to 820 Hz.
It features low noise, digital output, and low power consumption, making it widely applicable in semiconductors, sorting, etc.
Specifications
Specifications
Product Model
NS-615AS-10GE
Detector Type
InGaAs short-wave infrared focal plane detector
Spectral Response Range
0.9-1.7μm
Pixel Pitch
15μm
Resolution
640×512
Frame Rate
825Hz
Effective Pixel Rate
≥99.8%
Integration Type
Snapshot global shutter
Exposure Time Range
5us~20ms(LG)
Cooled Mode
TEC 1
Output Data Depth
8bit/10bit/12bit/14bit
Readout Noise (Typical value)
30e@Gain0
Optional Gain
3-level
Dynamic Range
50dB(Gain0),62dB(Gain1),72dB(Gain2)
Average Pixel Dark Current
≤80ke/s@20℃
On-board Image Processing
Non-uniformity correction, defective pixel compensation
Power Supply Range
5V-24V DC (12V DC recommended)
Typical Power Consumption @25℃
<8.4w(TEC OFF)
Digital Video
10GigE
Communication Interface
10GigE
Optical Interface
C-Mount
Weight
486g±10g
Dimensions
68mm×68mm×98mm
Operating Case Temperature
-40℃~+60℃
Storage Case Temperature
-40℃~+85℃
Vibration
50~2000Hz,0.01g^2/Hz, 3 axes
Shock
25g, 6ms, half-sine waveform, 3 axes/6 directions
Industry Solution
Pharmaceutical Research and Development
Process Defect Detection
Scientific Research
Sorting & Quality Control
