OHLE 3123 Uncooled Infrared Focal Plane Detector
- Model:
- OHLE 3123
Features
Resolution
384×288
Pixel Pitch
12μm
Frame Rate
≤60Hz
Power Consumption (25Hz, 300K)
<65mW
Dimensions
10.4mm×10.4mm×4.3mm
Highlights
Description
The OHLE 3123 is a super-wafer-level-packaged (SWLP) long-wave infrared sensor (384×288, 12μm) based on vanadium oxide (VOx) microbolometer. Its innovative window design overcomes integration environment limitations. Compatible with SMT mounting technology, it enables rapid mass production.
It features with an ultra-compact size, an ultra-lightweight design, high-qualiy imaging and ease of integration. OHLE3123 applies to multiple scenarios, e.g. outdoor night vision, industrial temperature measurement, security monitoring etc.
Specifications
Product Model
OHLE3123
Sensor Technology
Vanadium oxide microbolometer
Response Band
8‑14μm
Pixel Pitch
12μm
Resolution
384×288
NETD
<40mK(f/1.0,25Hz,300K)
Frame Rate
≤60Hz
Thermal Time Constant
<15ms
Digital Output Bits
14bits
Readout Mode
Progressive scan
Mirroring
X‑ and Y‑axis mirroring
Non‑Uniformity Correction
On‑chip 9‑bit non‑uniformity correction
Power Consumption
<60mW(25Hz,300K)
Packaging Dimensions(Excluding pin size)
10.4mm×10.4mm×4.3mm
Device Weight
≤0.6g
Packaging Type
36‑Pin SWLP
Output Polarity
Black hot
Temperature Measuring Range (f/1.0)
-40℃~+600℃
Operability Rate
≥99.5%
Input Interface
I2C interface (MODE0) 2‑bits parallel input interface (MODE1)
Operating Temperature Range
-40℃~+85℃
