RTD6122C High-Performance Ceramic Packaged LWIR Sensor
- Model:
- RTD6122C
Features
Resolution
640×512
Pixel Pitch
12μm
Detector Framerate
≤60Hz
Power Consumption
<170mW
Weight
≤6g
Size
22×22×4.58mm³ (without pin)
Highlights
Description
RTD6122C is a ceramic-packaged LWIR sensor (640×512, 12μm) based on vanadium oxide (VOx) microbolometer with an 8-14 µm wavelength range, high performance, low power consumption and high sensitivity.
RTD6122C applies to multiple scenarios, e.g. outdoor night vision, fire prevention, etc.
Specifications
Module
RTD6122C
Sensor Technology
Vanadium oxide microbolometer
Spectral Range
8‑14μm
Pixel Pitch
12μm
Array Format
640×512
NETD
<40mK (@f/1.0,50Hz,300K)
Frame Rate
≤60Hz
Thermal Time Constant
<12ms
Output Format
14bits
Read Mode
Progressive scan
Mirroring
X‑ and Y‑axis mirroring
Non‑uniformity Correction
On‑chip 6‑bit non‑uniformity correction
Power Consumption
<170mW(@50Hz,300K)
Size
22×22×4.58mm³ (without pin)
Weigh
≤6g
Package Type
32‑Pin Ceramic
Output Polarity
White hot
Wide Dynamic Range Mode
Support -40~600ºC temperature measurement (@f/1.0)
Operability
≥99.5%
Input Interface
2‑bits parallel input interface
Operating Temperature Range
-40°C~+85°C
