RTDS123C High-Performance Ceramic Packaged LWIR Sensor
- Model:
- RTDS123C
Features
Pixel Pitch
12μm
Frame Rate
25/30/50 Hz
Array Format
1280×1024
Power Consumption
<300 mW
Size
27×27×4.6 mm³
Weight
≤10 g
Highlights
Description
RTDS123C is a ceramic-packaged LWIR sensor (1280×1024, 12μm) based on vanadium oxide (VOx) microbolometer with an 8-14 µm wavelength range, high-quality images with high performance and high sensitivity.
RTDS123C applies to multiple scenarios, e.g. industrial temperature measurement, outdoor night vision, etc.
Specifications
Module
RTDS123C
Sensor Technology
Vanadium oxide microbolometer
Spectral Range
8‑14μm
Pixel Pitch
12μm
Array Format
1280×1024
NETD
<40mK (@f/1.0,30Hz,300K)
Frame Rate
25Hz/30Hz/50Hz
Thermal Time Constant
<15ms
Output Format
14bits(25Hz/30Hz)、13bits(50Hz)
Read Mode
Progressive scan
Mirroring
X‑ and Y‑axis mirroring
Non‑uniformity Correction
On‑chip 6‑bit non‑uniformity correction
Power Consumption
<300mW(@30Hz,300K)
Size
27×27×4.6mm³ (without pin)
Weigh
≤10g
Package Type
56‑Pin Ceramic
Output Polarity
White hot
Wide Dynamic Range Mode
Support -40~600ºC temperature measurement (@f/1.0)
Operability
≥99.5%
Input Interface
6‑bits parallel input interface
Operating Temperature Range
-40°C~+85°C
Industry Solution
Security Monitoring
Fire Monitoring and Alarm
Outdoor Leisure
Industrial Applications
